Model: IA–BFM–08
Automated Secondary Packaging for Pouch-to-Bag Applications
The IA–BFM–08 Pouch in Bag Packer is a fully-automated, PLC-controlled system designed for high-speed collation and insertion of flexible pouches into outer bags. Ideal for FMCG, food, personal care, and pharmaceutical industries, this machine seamlessly integrates with upstream VFFS/HFFS machines to automate secondary packaging, enhance production speed, and ensure consistent, professional packaging quality.
| Feature | Specification |
|---|---|
| Model | IA–BFM–08 |
| Speed | Up to 6 bags per minute |
| Pouch Handling Rate | 150–200 pouches per minute |
| Stitching System | Fully automatic industrial sewing head with auto thread cutting |
| Bag Placement | Semi-automatic or fully automatic bag feeding options |
| Control System | PLC with Touchscreen HMI (4” / 7”) |
| Bag Types | Laminated, paper, or poly outer bags |
| Pouch Compatibility | Flexible pouches from any VFFS/HFFS machine |
| Power Supply | 415V, 3 Phase, 50 Hz |
| Air Supply | 6 bar, clean & dry |
Handles up to 200 pouches/minute with precise collation and insertion into outer bags.
Industrial sewing system with automatic thread trimming, break detection, and tension control.
Choose between semi-automatic bag loading or fully automatic bag feeding from magazine.
User-friendly interface for recipe management, speed adjustment, production counting, and fault diagnostics.
Soft-transfer mechanisms and guided collation prevent pouch damage and misalignment.
Adjustable guides and settings allow fast switching between pouch counts and bag sizes.
Full safety enclosure with interlocks, emergency stop, and sensor-based operation.
